A Tube Type Oil Skimmer is a surface oil skimmer that effectively removes floating surface oil. A closed-loop oleophilic tube floats across the surface of the water in a tank or pit drawing the free-floating oils. Along with the ceramic finger guides on the skimmer, a unique wiper combination is attached to the tube for oil removal. The skimmed oil is collected in a trough which flows by gravity to the oil sump.
Tube Type Oil Skimmer Overview
We offer a Tube Oil Skimmer for the removal of floating surface oil. The skimmer is electric-driven at a fixed speed. It is available in two variants viz., single pulley and double pulley. For ease of maintenance, we also offer a swing arm option.
Tube Type Oil Skimmer Specifications
Capacity: 0 to 200 LPH
Tube Diameter: 19 mm/ 25 mm
Tube Length: Standard 5 m & higher as per site requirement
Skimmer MOC: MSPC/ MSEP/ SS 304/ SS 316
Tube MOC: Special Oleophilic Polymer
Finger MOC: Ceramic
Pulley: Single / Double
Pulley MOC: Al/ SS 304/ SS 316/ Nylon
Motor: Flameproof/ Non-flameproof
Mounting: Floor/ Cantilever Pole
Accessories: PVC Hose
